EdbPointsBox3D Class Reference

collection of 3D points More...

#include <EdbVirtual.h>

Inheritance diagram for EdbPointsBox3D:

Collaboration diagram for EdbPointsBox3D:

Public Member Functions
	EdbPointsBox3D ()
virtual	~EdbPointsBox3D ()
Public Member Functions inherited from EdbPointsBox2D
virtual EdbPoint *	At (int i) const =0
virtual Float_t	DeltaX ()
virtual Float_t	DeltaY ()
virtual void	DrawPoints (int style=23, int col=4, float size=1.)
	EdbPointsBox2D ()
	EdbPointsBox2D (const EdbPointsBox2D &pb)
virtual const EdbAffine2D *	GetKeep () const
virtual void	GetKeep (EdbAffine2D &aff)
virtual Int_t	N () const =0
virtual void	Print (Option_t *opt="") const
virtual void	Retransform ()
virtual void	Rotate (float angle)
virtual void	ScaleX (float scaleFactor)
virtual void	ScaleY (float scaleFactor)
virtual void	SetKeep (float a11, float a12, float a21, float a22, float b1, float b2)
virtual void	SetX (float x)
virtual void	SetY (float y)
virtual void	SetZ (float z)
virtual void	ShiftX (float offset)
virtual void	ShiftY (float offset)
virtual void	SmearXY (float sigmax, float sigmay)
virtual void	Substruct (EdbPointsBox2D *b)
virtual void	Transform (const EdbAffine2D *a)
virtual Float_t	X () const
virtual TH1F *	Xhist ()
virtual Float_t	Xmax () const
virtual Float_t	Xmin () const
virtual TH2F *	XYhist ()
virtual Float_t	Y () const
virtual TH1F *	Yhist ()
virtual Float_t	Ymax () const
virtual Float_t	Ymin () const
virtual Float_t	Z () const
virtual	~EdbPointsBox2D ()
Public Member Functions inherited from EdbPoint3D
virtual void	Print (Option_t *opt="") const
virtual void	SetZ (float z)=0
virtual void	Substruct (EdbPoint *p)
virtual void	Test () const
virtual void	TestPoint3D () const
virtual void	Transform (const EdbAffine3D *a)
virtual Float_t	Z () const =0
virtual	~EdbPoint3D ()
Public Member Functions inherited from EdbPoint2D
virtual void	Print (Option_t *opt="") const
virtual void	SetX (float x)=0
virtual void	SetY (float y)=0
virtual void	SetZ (float z)
virtual void	Substruct (EdbPoint *p)
virtual void	Test () const
virtual void	TestPoint2D () const
virtual void	Transform (const EdbAffine2D *a)
virtual Float_t	X () const =0
virtual Float_t	Y () const =0
virtual Float_t	Z () const
virtual	~EdbPoint2D ()
Public Member Functions inherited from EdbPoint
virtual void	SetX (float x)=0
virtual void	SetY (float y)=0
virtual void	SetZ (float z)=0
virtual void	Substruct (EdbPoint *p)=0
virtual void	Test () const
virtual void	Transform (const EdbAffine2D *a)
virtual void	Transform (const EdbAffine3D *a)
virtual Float_t	X () const =0
virtual Float_t	Y () const =0
virtual Float_t	Z () const =0
virtual	~EdbPoint ()

Detailed Description

collection of 3D points

Constructor & Destructor Documentation

EdbPointsBox3D()

EdbPointsBox3D::EdbPointsBox3D ( )

inline

: EdbPointsBox2D() {}

~EdbPointsBox3D()

virtual EdbPointsBox3D::~EdbPointsBox3D ( )

inlinevirtual

{}

---

The documentation for this class was generated from the following file:

• /home/antonio/fedra_doxygen/src/libEdb/EdbVirtual.h
